Cut Kerdi membrane to the size of the pan and apply mortar to the top of the Schluter shower pan fill in all the waffles with the flat side of the trowel.

Kerdi shower drain install. What size spacers should I use if I need to install the drain before the KERDI-SHOWER-T-TS-TT tray. Measure and cut a section of pipe to connect the KERDI-DRAIN to the odor trap below the floor. Any leveling must be done prior to shower tray installation.

Press the KERDI-DRAIN firmly into the mortar for full support of the bonding flange. This video will show you the complete installation from start to finish of the Schluter-KERDI-SHOWER-KIT. The Schluter-KERDI-SHOWER-KIT contains all the co.

Clean excess mortar from the bonding flange to prepare for the KERDI collar installation. As an alternative to KERDISEAL- PS-MV KERDI-FIX or other suitable sealant can be used to seal pipe protrusions and protect moisturesensitive solid backing panels at the mixing valve. First the Schluter-KERDI-DRAIN is installed in conjunction with either a sloped mortar bed or the Schluter-KERDI-SHOWER-T-TS-TT prefabricated foam trays.

The substrate must be clean even and load bearing. The KERDI-SHOWER-TT is also available in a neo angle configuration in 38 x 38 97 x 97 cm. Prepare the odor trap cut section of pipe and KERDI-DRAIN with cleaner primer and ABS or PVC cement per the solvent cement manufacturers instructions and connect.

First the Schluter-KERDI-DRAIN is installed in conjunction with either a sloped mortar bed or the Schluter-KERDI-SHOWER-ST prefabricated foam tray. The KERDI-DRAIN provides a simple and secure connection to the Schluter-KERDI waterproofing membrane at the top of the. Next we will install the KERDI-DRAIN.

All Schluter products are available at your local Mosaic Tile location. With lengths from 20 to 72 50 cm to 180 cm in 4 10 cm increments KERDI-LINE can fit virtually any shower design. The drain outlet is approximately 2 18 oc.

Schluter system building schluter kdh2 pvc fl kerdi drain h prep a shower for tile with schluter kerdi kerdi drains la tuilerie drain outlet makes relocating showers Kerdi Drain In Concrete Floor A Better Way Ceramic TileKerdi Drain In Concrete Floor A Better Way Ceramic TileKerdi Drain Rough In Ceramic Tile Advice Forums John BridgeKerdi Read More. Fill the step in the shower tray and the area surrounding the hole in the subfloor completely with thin-set mortar. And KERDI-SEAL-MV at the mixing valve.

The center section of the KERDI-SHOWER tray can be removed and used to establish the appropriate elevation of the KERDI-DRAIN. From the edge of the wall board. The KERDI-DRAIN provides a simple and secure connection to the Schluter-KERDI waterproofing membrane at the top of the assembly via the unique integrated bonding flange.

The neo-angle tray features an off-center drain placement. How far from the wall is the KERDI-LINE linear drain installed. KERDI-SHOWER pre-fabricated trays are ideal for constructing a shower base and designed to integrate with the Schluter Shower System.

12 305 cm from the 38 sides of the tray. Apply ALL-SET around the shower drain and glue it to the P-Trap below the shower pan. Kerdi Board 000 Mud 535Tile 1134Drain 3122Floor 3525Grout 4751 Complete bathroom install with Schluter Kerdi-board Kerdi-Line drain Walker Zanger ce.

Cut drain riser to correct length to position Kerdi drain just above the concrete floor. Install KERDI-LINE adjacent to the wall or at intermediate locations of your shower floorand then choose the drain grate that best matches your décor and desired finished look. When installing KERDI-DRAIN over wood subs trates the minimum thickness of mortar required at the perimeter of the bonding flange is 1 25 mm.

In our prior video we discussed how to dry fit the drain pipe and cut the ABS to size. Install KERDI-SEAL-PS pipe seals at showerhead body sprays etc. Cut 4 ABS to the correct length to position the top of the coupler so that it will be touching the bottom of the Kerdi drain when installed.

Please refer to the diagram below to find your tray size. The plumbing is in place and must be secured prior to installation. It is installed directly against the wall so that the channel body support is in contact with the wall.

Assemble the components and verify the fit.
